Secrets SDK - Protection of secret data using fingerprint
|
 |
Thanks to the features of Fx3000 fingerprint scanner (Match on Board, on board encryption, direct management of the Smart Card reader), Secrets SDK provides a secure way to manage an archive of secret data protected by fingerprints: the archive is stored on Fx3000 or on a Smart Card. The stored “secrets” consist of any kind of data (passwords, file etc) that might need protection: the protected data can be retrieved from the Fx3000 after a successful fingerprint verification. When an application, integrating Secrets SDK, needs to retrieve a “secret” stored on Fx3000, the scanner automatically requires verification of the fingerprint : the protected data is sent to the application only if the verification is successful. The archive of secrets can be stored on a Smart Card in order to allow the maximum privacy of data and the highest security.
Brochure (in formato PDF). Protection of Data
Secrets SDK provides a secure way for managing an archive of secret data. The archive is stored inside the Fx3000 scanner or on a Smart Card. Data is stored in an encrypted form and protected by fingerprints: each “secret” stored in the archive can be retrieved only after a successful fingerprint verification.
Secure Archive of secret Data
The archive of secret data (passwords, files etc) is created and encrypted inside the Fx3000 (and optionally saved on a Smart Card). A fingerprint is also acquired as protection of the archive: every time a secret data has to be retrieved from the archive a fingerprint verification is performed by the Fx3000. If the verification is successful the required data is decrypted and returned.
Archive Management
Secrets SDK provides all the functions needed to manage the archive: add and delete secrets, open, save and close the archive, management of request of specific secret. All the operations that modify or require the access to secrets are enabled after a successful fingerprint verification..
Match On Board
The fingerprint verification is performed inside the Fx3000 scanner thanks to its Match On Board feature. The fingerprint represents the access key to the protected data.
Smart Card
Fx3000 enables the direct management of the Smart Card reader: thanks to this feature the archive and the fingerprint can be stored on a Smart Card avoiding any data being transmitted through the computer (which is much more vulnerable to attacks). In this way the archive always remains in the owners hands, encrypted and protected by the finger.
PIN
In order to increase the archive security a PIN can be set for further protection of the archive. If a PIN is set, every time a secret has to be retrieved, the user also needs to digit the PIN after the fingerprint verification.
Cifratura
The archive is maintained in the Fx3000 memory in an encrypted way. A specific secret is decrypted after a fingerprint verification: in other words the secret is made available in clear only when it is required.
